Tycon Power 48V 802.3af/at input, Switch Selectable 18V or 24V 24W Gigabit POE Out Power Source/Inserter

The TP-POE-1824 is a unique PoE adapter which converts an 802.3af/at 48VDC PoE input into an 18 or 24VDC regulated passive PoE output. The PoE output voltage is external jumper selectable and capable of up to 25W power output. The PoE input is IEEE 802.3af/at compatible so the TP-POE-1824 will work with standard 802.3af/at compliant PoE switches or routers. This model, TP-POE-1824G, is 10/100/1000MB compatible and has a 24W output. Product Features • Converts 48V 802.3af/at PoE Input to 18V or 24V Passive PoE Output • Run Non-Compliant Equipment on 802.3af/at PoE switches • PoE Output Switchable Between 18VDC and 24VDC • Remotely Power Equipment thru CAT5 Cable up to 100m • Short Circuit, Over Current and Over Voltage Protection • High Temperature Operation • Compact Size - Floor / Desktop / Wall Mount Product Specifications • DC PoE Output Voltage: 18V or 24V (switchable) • Overvoltage Protection: 22V or 28V • Ethernet Interface Speed: 10/100/1000 • PoE Input (IEEE 802.3af/at): 36 - 60VDC • Output Current:     -1A @ 18V     -1A @ 24V • Output Power: 24W Max • Load Regulation: 5% • Ripple / Noise: 2% • EMC Standards: FCC Class B NE55022 Class B • Safety Standards: UL1950, CSA 22,2 & TUV EN60950 • Operating Temperature: -30 to 60°C (-22 to 140°F) • Operating Humidity: 5% - 90% • Storage Temperature: -40 to 80°C (-40 to 176°F) • Dimensions: 85 x 76 x 36mm (3.4 x 3 x 1.14") • Weight: 150g (5.3oz) Product Documentation TP-POE-1824G Datasheet Tycon Power Learning Center Presentation
